Instrumentation
![Placeholder](../../images/studentsusesem.png)
A scanning electron microscope, acquired in 2016 with a grant from the National Science Foundation, provides a powerful tool for students, faculty, and visiting researchers to study the structure and composition of rocks, minerals, shells, and corals.
![Image of microstructure from the electron backscatter diffraction](../../images/ebsd-kikuchiful-cropped.jpeg)
The EBSD system, by HKL Technology Inc., is an instrument used for the observation and analysis of microstructures and for phase identification.
![Buoy](../../images/buoy/buoy-edited.png)
The Bowdoin Buoy
Made possible by a grant from the National Science Foundation and the result of a partnership among Bowdoin, Bigelow Laboratory, and St. Joseph's College, the scientific buoy near the Schiller Coastal Studies Center in Harpswell Sound was installed to study Harmful Algal Blooms (HABs).
![Titrator](../../images/titrator2.jpg)
![Gaz analyzer](../../images/gas-analyzer-outside.jpeg)
Trace Gas Analyzer LI-7810
High performance CO2, CH4, and N2O gas analyzers for the field and lab.
![Gas Chromatograph](../../images/gas-chromatograph.jpg)
Varian 450 GC
The Gas Chromatograph allows us the measure the concentration of CO2, CH4, and N2O gas in air samples.
![High-pressure Liquid Chromatography (HPLC)](../../images/hplc-high-pressure-liquid-chromatography-phytoplankton-id-corrected.jpg)
Agilent 1260 Infinify II HPLC
HPLC separates compounds dissolved in a liquid sample and allows qualitative and quantitative analysis of what components and how much of each component are contained in the sample.
![Laser in-situ scatter transmissometry machine](../../images/lisst-laser-in-situ-scattering-and-transmissiometry.jpg)
LISST-100X
The LISST is a submersible multi-parameter system for in-situ observations of particle size distribution and volume concentration.
![Student pointing at nutrient analyzer](../../images/nutrient-analyzer-student.jpg)
Nutrient Analyzer
The Smartchem 170 can analyze nitrate, ammonia, ortho-phosphate, Kjeldahl nitrogen and phosphate and silicate in water and soil samples.
![Spectrophotometer](../../images/spectrophoto-meter-phytoplankton-absorbtion-light-visible-ultravioletjpg.jpg)
Cary 300 Spec
This instrument measures the light absorbed, transmitted, or reflected by the sample at each wavelength in the UV and Visible spectrum.
![Salinity, Temperature, and Depth System (STD)](../../images/std-salinity-temperature-depth-oxygen-densityjpg.jpg)
Seabird CTD
The SBE 19plus V2 SeaCAT measures conductivity, temperature, and pressure in marine or fresh water environments.
![YSI 6600 machine](../../images/ysi-6600-temp-salinity-turbidity-oxygen-chlorophyll-ph.jpg)
Measures temperature, salinity, turbidity, oxygen, chlorophyll and pH levels of seawater.
